| Trailer Appearance | |
| Dimension (screen up) | 24’7″×6’10″×10’5″ |
| Chassis | German-Made AIKO |
| Gross weight | 3500kg |
| Max speed | 100Km/h |
| Braking | Hydraulic braking |
| Axle | 2 axles, Bearing 5000kg |
| LED Screen | |
| Dimension | 18′(W)×9’10″(H) |
| Module Size | 9.8″(W)×9.8″(H) |
| Pixel Pitch | P3.91mm, P4.81mm, etc |
| Brightness | 5500cd/㎡ |
| Lifespan | 100,000 hours |
| Cabinet Material | Die-casting aluminum |
| Cabinet Size | 1’7″×3’3″ |
| Power Parameter | |
| Input Voltage | Three phases five wires 415V |
| Output Voltage | 220V |
| Inrush Current | 30A |
| Average Power Consumption | 250wh/㎡ |
| Multimedia Control System | |
| Video Processor | NOVA |
| Model | VX400S |
| Power Amplifier | 1000W |
| Speaker | Speaker 200W×4 |
| Hydraulic System | |
| Wind Proof Level | Level 8 |
| Supporting Legs | Stretching Distance 11″ |
| Hydraulic Lifting | Lifting Range 15’1″, Bearing 3000kg |
| Folding System | Fold the ear screens on 4pcs electric pushrods folded both sides |
| Rotation | Electric rotation 360 degrees |
| Wind Speed Sensor | Alarm with mobile APP |
| Trailer Appearance | |
| Dimension (screen up) | 24’7″×6’10″×10’5″ |
| Chassis | German-Made AIKO |
| Gross weight | 3500kg |
| Max speed | 100Km/h |
| Braking | Hydraulic braking |
| Axle | 2 axles, Bearing 5000kg |
| LED Screen | |
| Dimension | 18′(W)×9’10″(H) |
| Module Size | 9.8″(W)×9.8″(H) |
| Pixel Pitch | P3.91mm, P4.81mm, etc |
| Brightness | 5500cd/㎡ |
| Lifespan | 100,000 hours |
| Cabinet Material | Die-casting aluminum |
| Cabinet Size | 1’7″×3’3″ |
| Power Parameter | |
| Input Voltage | Three phases five wires 415V |
| Output Voltage | 220V |
| Inrush Current | 30A |
| Average Power Consumption | 250wh/㎡ |
| Multimedia Control System | |
| Video Processor | NOVA |
| Model | VX400S |
| Power Amplifier | 1000W |
| Speaker | Speaker 200W×4 |
| Hydraulic System | |
| Wind Proof Level | Level 8 |
| Supporting Legs | Stretching Distance 11″ |
| Hydraulic Lifting | Lifting Range 15’1″, Bearing 3000kg |
| Folding System | Fold the ear screens on 4pcs electric pushrods folded both sides |
| Rotation | Electric rotation 360 degrees |
| Wind Speed Sensor | Alarm with mobile APP |
